Optical Fiber Tester including optical power meter, optical light source, VFL, optical multimeter, optical variable attenuator,optical cable identifier, optical fiber ranger.


Description:

The TE202 series Laser Source offer excellent stability and portability for fiber optic testing. It can provide 1 to 4 wavelength export according to the specific requirements including the 650nm850nm1300nm1310n1490nm1550nm1625nm. And works at a variety of modulation frequency (CW, 270HZ, 1KHZ, 2KHZ).

It is widely used in optical fiber communications, CATV, optical fiber sensing, optical information processing field. It is an important fiber optical testing instrument in research and engineering.


Features :
Good stability in output power
Large LCD display and backlight
Battery power display


Application:

1. Maintenance Telecom

2. Maintenance CATV
3. Test Lab of Fiber Optic

4. Optical fiber sensors


Specifications:

Type
TE202
Emitter Type
FP-LD
Wavelength(nm)
650 850 1300 1310 1490 1550 1625(1-4 wavelength)
Optical Connector
FC(SC/ST can be optional)
Ouput Power(dBm)
≥ 3mw @ 650nm; ≥
-7dBm @ 850/1300nm
 ≥ -7/0dBm @ 1310/1490/1550/1625nm
Output Stability(dB)
±0.04@20℃@15min
Modulation Frequencies
CW,2Hz@650nm;CW,270Hz,1KHz,2KHz@Others
Fiber Type
SM、MM
Power Supply
1pcs 9V Battery
working time(h)
20 hours
Operating Temperature(℃)
-10~+50
Storage Temperature(℃)
-20~+70
Dimension(mm)
170*100*50mm
Weight(g)
400g(Include battery)
